Revolving Blade Upright CNC Sponge Cutting Machine For Flexible Sponge

Brand Name : D&T

Model Number : DT - R2012V/DTC-R2012H

Certification : CE

Place of Origin : Zhejiang,China

MOQ : 1 set

Price : USD 35000 - 65000 / set

Payment Terms : T/T, L/C, Paypal

Supply Ability : 20 sets / month

Delivery Time : 40 working days

Packaging Details : Film + wooden box

Max. Product Size : L2800*W2200*H1000mm

Cutting Speed : 0-40m/min

Overall Power : 11kw

Overall Weight : 2500kg

Colour : Customized

Product Name : Revolving Blade Foam Upright CNC Sponge Cutting Machine for flexible sponge

Contact Now

Revolving Blade Foam Upright CNC Sponge Cutting Machine for flexible sponge
Product Description

1. Technical Data

Main Technical Specification

Model DTC-R2012V/DTC-R2012H
Max.Product Size L2800*W2200*H1000mm
Control System Industrial Computer+Windows XP
Software D&T revolving Profiler
Cutting Speed 0~40m/min (Adjustable)
Overall Power 11kw,380V,50Hz
Overall Weight 2500kg
Overall Dimension L6000*W5630*H3000m




Revolving Blade Upright CNC Sponge Cutting Machine For Flexible Sponge

2. Main features

1) Linear structure is simple, convenient installation and maintenance.

2) Pneumatic, electrical and operating parts adopt world advanced brand components.

3) High pressure double crank control mold opening and closing.

4) High degree of automation, high degree of intelligence, no pollution. The joint is connected with the air conveying device, and can be directly connected with the filling machine.

Our services

Pre-sale service

Query and consultation support.

* Sample testing support.

* Check out our factories.


Revolving Blade Upright CNC Sponge Cutting Machine For Flexible Sponge

Packaging
Size
L2800*W2200*H1000mm
Weight
2500kg
Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.

Terms:

Terms of Payment: 30% advance payment by T/T upon signing the contract
70% covered by T/T before delivery
Delivery: 45 working days after receipt of advance payment.

Installation and Start-up:

One technician will be assigned to coordinate installation,
commissioning and training,
cost for flight and suitable accommodation plus
USD80/day per person will be charged additionally.
Warranty: 12 months limited warranty starting
from date of delivery excluding wear parts.
Shipping cost for parts to be replaced

during warranty period have to be borne by the customer.
